Communication with the Alarm Control Panel via Data Bus or Serial Port, How is it Possible?

In a traditional setup, universal communicators are typically connected to the alarm’s telephone line (TIP-RING). Trikdis specialized communicators (alarm communicators) are uniquely capable of connecting to the internal communication channel of the alarm system. Depending on the manufacturer, this can be achieved in two ways:

  • The Trikdis communicator must be connected to a data bus, for example, with DSC, Honeywell, CROW, etc.,
  • With Paradox and Texecom panels, the serial port can be used.

The essence of the technology is that the connected Trikdis communicator knows the language of the alarm control panel and can interpret the messages sent to it (unidirectional communication). Just like the keypads or other peripherals, the communicator also receives and understands the events sent by the system and will forward them to the client and/or central monitoring as per the settings.

What are the advantages?

  • Simpler than the traditional TIP RING connection
  • More reliable
  • Faster to install
  • Faster communication

Direct Control

Direct control has additional advantages. Beyond the above, the communicator not only receives events from the panel for forwarding, but some of the functions available on the keypad are also accessible, meaning this is a bidirectional communication.

Additional advantages of direct control

  • The entire system or any partition can be armed or disarmed using the user code (the same one used on the keypad)
  • Automatic partition and zone mapping
  • Detection of mapped zone status
    (A frequent question, but this does not mean there is constant status display in the user app, the information on the zone status is only available when an event occurs and the app updates)
  • Zone bypass
  • The outputs remain available for other control – there is no need to wire an output as a key switch for arming/disarming, it is done directly via the data bus or serial port

What is this solution not capable of?

  • The PGM outputs cannot be controlled on the alarm control panel
  • The alarm control panel cannot be programmed remotely or updated (TRIKDIS devices can be updated)

Which Trikdis communicators are capable of the above functions?

Centrales de alarma conectables mediante bus de datos o puerto serie

El Trikdis E16, G16, GT, GT+, GET son compatibles con todas las centrales de alarma indicadas abajo . La principal ventaja de estos módulos de comunicación especializados de Trikdis es que los eventos se transmiten a través del bus de datos o el puerto serie.

Alarmzentralen, die blau markiert son, können direkt (Scharf-/Unscharfschaltung) über die puerto serie oder den Bus de datos gesteuert werden – ganz ohne zusätzliche Verdrahtung.

Las centrales marcadas en negro markiert son, reciben eventos a través del bus de datos o el puerto serie , pero requieren zonas de interruptor de llave y cableado adicional para el control completo del sistema de alarma .

PARADOX
Puerto serie
Spectra SP4000, SP5500, SP5500+*, SP6000, SP6000+*, SP7000, SP7000+*, SP65 , 1727, 1728, 1738
Magellan MG5000, MG5050, MG5050+*, MG5050E
DIGIPLEX EVO48, NE96, EVO96, EVO192*, EVOHD* (*Fw. über 7.50)
ESPRIT E55, 728ULT, 738ULT
Para el control directo, el firmware de las centrales PARADOX debe ser al menos la versión V.4.
* El puerto serie en las centrales nuevas marcadas está bloqueado de fábrica. El puerto debe activarse antes de poder comunicarse con un dispositivo externo.
DSC
Bus de datos
PC585, PC1565, PC1616, PC1832, PC1864 , PC1404, PC5015, PC5020
DSC Power Series NEO family
Línea telefónica
TIP-RING
DSC Power Series NEO

¿Los comunicadores especiales Trikdis son compatibles con la familia DSC Power Series NEO?

¡NO! Utiliza los comunicadores universales E16T, G16T, GT, GT+, GET con conexión de línea telefónica (TIP RING).

Lee los detalles: DSC Power Series NEO y comunicadores Trikdis: Compatibilidad y soluciones

Interlogix
Bus de datos
NetworX (Caddx) NX-4v2, NX-6v2, NX-8v2, NX-8e
Texecom
Puerto serie
Premier 24, 48, 88, 168, 412, 816, 832, 832+
Premier Elite 12, 24, 48, 64, 88, 168
Innerrange
Bus de datos
Inception
Honeywell
Bus de datos
Ademco Vista-15, Ademco Vista-20, Ademco Vista-48
Crow
Bus de datos
Runner 4/8, 8/16


¿No encuentras tu sistema en la lista?

Los comunicadores universales E16T, G16T, GT, GT+, GET son compatibles con cualquier central de alarma mediante conexión TIP RING.

Trikdis E16T Ethernet okos átjelző Trikdis G16T GSM / IP okos átjelző Trikdis GT okos átjelző Trikdis GTplus okos átjelző Trikdis GET okos átjelző

What smart solutions can be utilized with Trikdis communicators?

Depending on the device, Trikdis smart communicators and Trikdis smart alarm control panels have one or more outputs. These outputs can be used for control: gate or garage door opening, heating, irrigation, lighting control, etc. These can be enhanced with some sensors, such as light, liquid level, temperature sensors, to create a simpler smart home system, where the communicator’s input can be used as feedback (e.g., if the gate or garage door is open).
